Dates: July 21-23, 2020
Time: Course sessions 10:00 am to noon, 12:30 pm to 3:30 pm Central

Extra Q&A Sessions 9:30 am to 10:00 am, 3:30 pm to 4:00 pm Central
Where: On-line (at your office or home computer)
Cost: $595 per participant before COB Thursday, July 9, 2020.

Includes: 350+ page hardcopy textbook updated to include ASME Y14.5-2018 revisions is sent to each participant within the continental US prior to the webinar.

Pre/post assessment

Various references, GD&T inspection calculators, and other tolerancing tools

Certificate of Completion

Customized exercises based on participant drawings, views, or examples

On-going email and telephone support from ITR available.

Registration: Complete and submit the form to the right.

Credit card payment only. No refunds for participant cancellations.

Registration ends COB July 9, 2020 or when available seats are filled.
Inquiries: Dan Bauer at (915) 867-4500 or email dan.bauer@itr-sa.com.

GD&T is an international symbolic language used on mechanical engineering drawings to supplement and optimize traditional coordinate dimensioning and tolerancing. Dan Bauer from ITR holds Senior GD&T Certification from ASME and will be teaching GD&T Fundamentals including the following:

What is it, who uses it, and why
Metric and Inch dimensioning and tolerancing conventions
Major Elements of GD&T
Key elements and major changes to the last three revisions to Y14.5 and ISO 1101
Aerospace and automotive specific standards, requirements, and exceptions to Y14.5
How to Interpret Feature Control Frames, Datums, and Basic Dimensions
Inspection and measurement options for of each of the 14 GD&T Symbols
Advantages and Disadvantages of GD&T for Design, Manufacturing, and Inspection
Basic Steps for Applying Coordinate and Geometric Dimensioning and Tolerancing to New Designs or Drawings
Customized application and interpretation exercises based on Participant Drawings*

This program is appropriate for all management, design, manufacturing, quality, inspection, purchasing personnel to understand the benefits and proper application and interpretation of GD&T.

*Participants are encouraged to submit drawings (with or without GD&T) to the instructor before and during the seminar for review during the presentation.
